Question by seandolan · Jul 02, 2018 at 04:41 PM · 3doptimizationprocedural mesh

Procedural mesh redrawing textures causes in game fps drop. Is there a way to optimise this?

I have a procedural mesh drawing a grid of floor textures on in a 3D environment. The player can change the tiles by drawing on them. I am experiencing a significant drop in fps just doing the updating of the new textures. I know enough to understand that this is creating a lot of work, but not enough to understand how to optimise this. I added 2 boolean's that just flag instead of running the update in one whole chunk and this has helped out with about a 10% reduction in the lag it's all causing. Any help would be greatly appreciated. I feel that there should be a more efficient way to run the UpdateMesh as it feels like it's doing more work than it would need to, just to update the new floor tiles.

 using System.Collections;
 using System.Collections.Generic;
 using UnityEngine;

 public class BuildGrid:MonoBehaviour {

     public int floor = 0;

     public bool buildPending = false;
     public bool updatePending = false;

     List<Vector3> newVertices = new List<Vector3>();
     List<int> newTriangles = new List<int>();
     List<Vector2> newUV = new List<Vector2>();

     List<Vector3> colVertices = new List<Vector3>();
     List<int> colTriangles = new List<int>();
     int colCount;

     Mesh mesh;
     MeshCollider col;

     float tUnit = 0.1f;

     int squareCount;

     void Start() {
         mesh = GetComponent<MeshFilter>().mesh;
         col = GetComponent<MeshCollider>();
         buildPending = true;
     }

     void FixedUpdate() {
         if(buildPending) {
             buildPending = false;
             BuildMesh();
         }
         if(updatePending) {
             updatePending = false;
             UpdateMesh();
         }
     }

     void BuildMesh() {
         for(int px = 0; px < FloorManager.Instance.width; px++) {
             for(int py = 0; py < FloorManager.Instance.height; py++) {
                 GenCollider(px,py);
                 GenSquare(px,py,TextureMap(StoreManager.Instance.GetStoreColor(FloorManager.Instance.floorLayout[floor,px,py])));
             }
         }
         updatePending = true;
     }
     void UpdateMesh() {
         mesh.Clear();
         mesh.vertices = newVertices.ToArray();
         mesh.triangles = newTriangles.ToArray();
         mesh.uv = newUV.ToArray();
         mesh.RecalculateNormals();

         newVertices.Clear();
         newTriangles.Clear();
         newUV.Clear();
         squareCount = 0;

         Mesh newMesh = new Mesh {
             vertices = colVertices.ToArray(),
             triangles = colTriangles.ToArray()
         };
         col.sharedMesh = newMesh;

         colVertices.Clear();
         colTriangles.Clear();
         colCount = 0;
     }

     Vector2 TextureMap(int _number) {
         return new Vector2((_number - (_number % 10)) / 10,_number % 10);

     }

     void GenCollider(int x,int y) {
         colVertices.Add(new Vector3(x,0,y - 1));
         colVertices.Add(new Vector3(x,0,y));
         colVertices.Add(new Vector3(x + 1,0,y));
         colVertices.Add(new Vector3(x + 1,0,y - 1));

         ColliderTriangles();

         colCount++;
     }

     void ColliderTriangles() {
         colTriangles.Add(colCount * 4);
         colTriangles.Add((colCount * 4) + 1);
         colTriangles.Add((colCount * 4) + 3);
         colTriangles.Add((colCount * 4) + 1);
         colTriangles.Add((colCount * 4) + 2);
         colTriangles.Add((colCount * 4) + 3);
     }

     void GenSquare(int x,int y,Vector2 texture) {
         newVertices.Add(new Vector3(x,0,y));
         newVertices.Add(new Vector3(x + 1.0f,0,y));
         newVertices.Add(new Vector3(x + 1.0f,0,y - 1.0f));
         newVertices.Add(new Vector3(x,0,y - 1.0f));

         newTriangles.Add(squareCount * 4);
         newTriangles.Add((squareCount * 4) + 1);
         newTriangles.Add((squareCount * 4) + 3);
         newTriangles.Add((squareCount * 4) + 1);
         newTriangles.Add((squareCount * 4) + 2);
         newTriangles.Add((squareCount * 4) + 3);

         newUV.Add(new Vector2(tUnit * texture.x + 0.01f,tUnit * texture.y + tUnit - 0.01f));
         newUV.Add(new Vector2(tUnit * texture.x + tUnit - 0.01f,tUnit * texture.y + tUnit - 0.01f));
         newUV.Add(new Vector2(tUnit * texture.x + tUnit - 0.01f,tUnit * texture.y + 0.01f));
         newUV.Add(new Vector2(tUnit * texture.x + 0.01f,tUnit * texture.y + 0.01f));

         squareCount++;
     }

 }


Texture for Colours

Comment
Add comment · Show 1
10 |3000 characters needed characters left characters exceeded
▼
  • Viewable by all users
  • Viewable by moderators
  • Viewable by moderators and the original poster
  • Advanced visibility
Viewable by all users
avatar image seandolan · Jul 03, 2018 at 06:58 AM 0
Share

Would breaking the following code into parts (like 0 to 9, then 10 to 19, etc) improve the performance?

 void Build$$anonymous$$esh() {
          for(int px = 0; px < Floor$$anonymous$$anager.Instance.width; px++) {
              for(int py = 0; py < Floor$$anonymous$$anager.Instance.height; py++) {
                  GenCollider(px,py);
                  GenSquare(px,py,Texture$$anonymous$$ap(Store$$anonymous$$anager.Instance.GetStoreColor(Floor$$anonymous$$anager.Instance.floorLayout[floor,px,py])));
              }
          }
          updatePending = true;
      }

0 Replies
